450 TON Trenchless Horizontal Directional Drilling Machine pipe pulling HDD machine DL4500

Product Categories

Beijing Silk Road Enterprise Management Services Co.,LTD

Contact Now

Name: 450 TON Trenchless Horizontal Directional Drilling Machine pipe pulling HDD machine DL4500
Brand: DILONG
Price: 1 USD

Brand Name : DILONG

Model Number : DL4500

Place of Origin : NANJING

MOQ : ONE SET

Price : NEED DISCUSS

Payment Terms : L/C, T/T

Supply Ability : 30 Units PER YEAR

Delivery Time : After advance payment in 45 days

Certification : ISO9001

ENGINE : CUMMINS 559 KW

THRUST : 4500 KN

PULLBACK : 4500 KN

TORQUE : 120000

ROTARY SPEED : 70 RPM

WEIGHT : 60 TON

Contact Now

450 TON Trenchless Horizontal directional Drilling machine pipe pulling HDD machine DL4500

KEY POINT:

Steel rubber crawler, good strength, easy installation and maintenance
Multiplayer cab design, with air conditioning, vision, making the operation more comfortable
Wire walking, safe and reliable
Semi-automatic drill pipe brackets, simple and reliable, with 3 tons crane use, easy handling drill

A world-class brand PALL filters ensure clean hydraulic system, making the life of the original large

Specification:

Engine	kw	559/1800	Dimension(LWH)	mm	1882039653500
Max.thrust force	KN	4500	Weight	T	60
Max.pullback force	KN	4500	Diameter of drill rod	mm	Φ140
Max.torque	N.m	120000	Lendht of drill rod	m	9.6
Max.Rotary speed	rpm	70	Max diameter of pullback pipe	mm	Φ1600
Max.Moving speed of power head	m/min	30	Incidence angle	.	9~15
Max.mud puump flow	L/min		Climbing angle	.	~14
Max.mud pressure	Mpa	10±0.5	Max pullback pipe length	m	~2000

450 TON Trenchless Horizontal Directional Drilling Machine pipe pulling HDD machine DL4500

Whatsapp number: 008618936869890
